PC PIPE

Polycarbonate pipes combine high transparency, outstanding impact strength, and good temperature resistance. Suitable for drinking-water systems, chemical transport, medical tubing, and lighting applications, PC pipe extrusion requires stable melt pressure and precise wall-thickness control. PIPPL self-balancing conical twin screws and wear-resistant dual-alloy barrels ensure consistent pipe quality and high production yield.

Key Features
• Self-balancing conical twin screw maintains melt pressure fluctuation below 1% for uniform wall thickness.
• Dual-alloy barrel offers exceptional wear and corrosion resistance for continuous high-speed pipe production.
• Low-shear plasticization preserves PC molecular weight and impact performance.
• Compatible with major pipe extruder brands for easy retrofit and upgrade.
• High finished product yield exceeding 95% under normal operating conditions.
Product Types
Transparent PC pipes, multi-layer pipes, and custom-profile tubing in a wide range of diameters and wall thicknesses.

Technical Specifications – Recommended PIPPL Screw & Barrel

Model (d/D)	Output (kg/h)	Barrel Material	Hardness / Life
45/90	50-80	38CrMoAlA + Dual Alloy	HRC58-65 / ≥24 months
55/110	100-160	38CrMoAlA + Dual Alloy	HRC58-65 / ≥24 months
65/132	180-280	38CrMoAlA + Dual Alloy	HRC58-65 / ≥24 months

Applications

Drinking-water piping, chemical process lines, medical fluid transport, LED lighting tubes, and protective conduit systems.

Customization Support

PIPPL designs screws and dual-alloy barrels matched to your specific pipe diameter range, wall thickness, and output targets. Complete process support from formula to finished pipe is available.
