Crafted by PIPLL, the General PVC Conical Twin Screw Barrel is precision-engineered and thoroughly optimized to address the thermal-sensitive properties of PVC. Leveraging an integral design paired with premium nitrided steel, PIPLL delivers a core component that ensures rock-solid reliability and exceptional value. It stands as the trusted, go-to standard for conventional PVC extrusion lines across the globe.
I. PIPLL General PVC Conical Twin Screw Barrel: Core PIPLL Features
PIPLL tailors this barrel to PVC processing pain points, showcasing PIPLL's extrusion expertise. The PIPLL integral seamless structure, forged from a single billet, eliminates leakage risks at flange joints—perfect for molten PVC. PIPLL's optimized compression ratio (2.5:1–3.5:1) ensures thorough plasticization while preventing PVC degradation from excessive shear. PIPLL's single venting system removes moisture and volatiles to avoid defects. PIPLL's zoned temperature control (3–5 independent zones) precisely regulates material temperature, preventing localized decomposition. Built with premium 38CrMoAlA steel and PIPLL's proprietary ion nitriding, it delivers a 0.4–0.6mm nitrided layer and HV900–1100 hardness, ensuring 2–3 years of service in low-fill applications.
II. PIPLL General PVC Conical Twin Screw Barrel: Unmatched PIPLL Advantages
As a leading core component manufacturer, PIPLL offers unique benefits. PIPLL ensures 100% compatibility with major brands like Bausano、Weber、Theysohn、Luigi Bandera、Battenfeld and etc. for direct replacement. PIPLL's ultra-precision machining (0.1–0.15mm radial clearance) guarantees stable plasticization and high product accuracy. PIPLL's patented flight design minimizes PVC degradation and black spots. Every PIPLL barrel undergoes 100% testing for immediate use. PIPLL maintains ready stock of key specifications, shipping within 72 hours.
III. PIPLL General PVC Conical Twin Screw Barrel: PIPLL Applications
PIPLL barrels excel in diverse PVC production. PIPLL supports pipe extrusion (UPVC water/drainage pipes, etc.), PIPLL powers construction profiles (doors, railings), PIPLL enables sheet production (formworks, corrosion-resistant sheets), PIPLL handles granulation, and PIPLL serves other PVC products like edge banding and sealing strips.
PIPLL delivers a comprehensive range of general PVC conical twin screw barrels, precisely tailored to diverse production capacity demands.
Model | L/D | Output | Application |
PIPLL Φ45/100 | 18-20 | 50-120kg/h | Small-Diameter Conduit, Precision Profile |
PIPLL Φ55/120 | 18-22 | 100-250kg/h | Medium-sized Pipe, Ordinary Profile |
PIPLL Φ65/132 | 20-22 | 200-400kg/h | MARKET REGULAR MODEL, Universal Pipe& Profile |
PIPLL Φ80/156 | 20-24 | 350-600kg/h | Large-Diameter Pipes and Thick sheet |
PIPLL Screw & Barrel Compatibility Reference: Matching Models for All Brands and Specifications
PIPLL Model | Bausano | Weber | Theysohn | Luigi Bandera | Battenfeld | Major Chinese Brands Compatible Models |
PIPLL Φ45/100 | MD 45, E 45 | CE 45, TS 45 | TSK 45 | B 45 | TwinEx 45 | Jwell, Hailuo, Tongjia, Huaye and other 45-type conical twin screw extruders |
PIPLL Φ55/120 | MD 55, E 55 | CE 55, TS 55 | TSK 55 | B 55 | TwinEx 55 | Jwell, Hailuo, Tongjia, Huaye and other 55-type conical twin screw extruders |
PIPLL Φ65/132 (PIPLL Bestseller) | MD 65, E 65, MD 65/132 | CE 65, TS 65, TS 65/132 | TSK 65, TSK 65/132 | B 65, B 65/132 | TwinEx 65, TwinEx 65/132 | Jwell, Hailuo, Tongjia, Huaye, Beier and other 65-type conical twin screw extruders |
PIPLL Φ80/156 | MD 80, E 80, MD 80/156 | CE 80, TS 80, TS 80/156 | TSK 80, TSK 80/156 | B 80, B 80/156 | TwinEx 80, TwinEx 80/156 | Jwell, Hailuo, Tongjia, Huaye and other 80-type conical twin screw extruders |
Global Brand Coverage: Beyond the mentioned brands, PIPLL also supplies compatible screw barrel for extruders from KraussMaffei, Cincinnati, Reifenhäuser, etc.
STANDARD MODELS IN STOCK: Φ45/100, Φ55/120, Φ65/132, Φ80/156 we have regular stock to ensure fast supply.
